Manufacturer:(CPT) Model Number:CLAA104XA02CW
Diagonal size:10.4inch Type:a-Si TFT-LCD,LCD module
Resolution:1024(RGB)×768 XGA 123PPI Pixel arrangement:RGB vertical strip
Display area:211.2(hor)×158.4(ver)mm Appearance size:236(hor)×174.3(ver)×7.4(thi)mm
Opening area:213.2(hor)×160.4(ver)mm Surface treatment: matte, Hard coating (3H)
Display brightness:400 cd/m²(Typ.) Contrast:500:1 (Typ.) (transmission)
Recommended viewing angle:6 o'clock Response time:25 (Typ.)(Tr+Td) ms
Viewing angle:70/70/60/80(Typ.)(CR≥10) Display mode:TN,normally white display,transmissive
Support color:262K,47% NTSC Light source type:WLED [3S13P], 30K hours, no driver
Weight:385g(Typ.) Application products:industrial and medical equipment
Frame rate:60Hz Touch technology:No touch
Interface 30 pins LVDS (1 ch, 6-bit), connector voltage:supply 3.3V (Typ.) (VCC)
Working temperature:20 ~ 70 °C Storage temperature:- --30 ~ 80 °C
(hor=horizontal,ver=vertical)
